Description
- Rated continuous current Icth: 1.0 x IN
- Rated short-time current Ith: 60 x IN, 1 sec.
- Operating voltage Um: 0.72 kV
- Insulation test voltage: 3 kV, Ueff, 50 Hz, 1 min.
- Rated frequency: 50 Hz
- Insulation class: E
ASG 210.3
Rated continuous current Icth: 1.0 x IN Rated short-time current Ith: 60 x IN, 1 sec. Operating voltage Um: 0.72 kV Insulation test voltage: 3 kV, Ueff, 50 Hz, 1 min. Rated frequency: 50 Hz Insulation class: E
Additional information
| Weight | 5106326 kg |
|---|---|
| Primary Current | |
| Secondary Current | |
| Burden (VA) | |
| Accuracy Class |
